Home > Wireless Module > Bluetooth Module > HM-13 Bluetooth V4.0 BLE/SPP Double Module Transparent Transmission DC 3.3V 50mA

HM-13 Bluetooth V4.0 BLE/SPP Double Module Transparent Transmission DC 3.3V 50mA

5 9
$8.75 $6.21
Time Remaining:
- OR - Add to Wish List

Product Introduction:
1.Bluetooth Specification:bluetooth V4.0 EDR and BLE
2.Serial Port Buffer Zone Size:512 bytes
3.Starting Up Time:balance mode 2s;high-speed mode 1s
4.Operating Mode:balance mode;high-speed mode
5.Transceive Distance:SPP 30m;BLE 60m
6.Communication Distance:SPP 50m;BLE 100m
7.Operating Way:when power on,it will automatically reset;RESETB pin can ne null
8.Operating Frequency:2.4GHz ISM band
9.Modulation Way:GFSK
10.Sensitivity:<=-84dBm at 0.1% BER
11.Transmission Rate:SPP-40% serial port efficiency;BLE-30% serial port efficiency
12.Safe Character:authorization and encryption
14.BLE Service:ATT,GATT,LE Service:0xFFE0,Char:0xFFE1
15.Power Consummption:SPP-13mA (average);BLE-9.5mA (average);standby 10-17mA
16.Power Supply Voltage:DC 3.3V/50mA
17.Operating Temperature:-5~80 centigrade

1.Industrial Remote Control,Telemetering
2.POS System,Gamepad
3.Car Detection Device
4.Battery Power Supply Medical Devices
5.Automation Data Collection
6.Bluetooth Remote Control Toys
7.Wireless LED Display System
8.Bluetooth Printer
9.Smart Home
