Product Introduction:
1.Size:63*48*16mm
2.Main chip:FR1205 (NMOS)
3.Input Control Voltage: DC 3V-24V
4.Maximum output control voltage is 55V, maximum circuit is 5A
5.Input control power and controlled power are completedly optocoupler isolated
6.4 bit output singal with indicator light
7.4 bit input signal low-level is valid with optocoupler isolation
8.Input can connect with SCM by using pins
9.Output with connection terminal if connects controlled equipment power supply will be convenient

I. Applications:
1.Can use SCM/PLC or other equipment output PWM signal to control DC motor speed testing,LED dimming etc
2.Can use SCM/PLC or other equipment output high/low level signal controlling output DC power

II. Connection Diagram:

III. Tested by ICStation Outstanding Customer Achim Döbler
