PCB Production & Processing Service
ICStation can provide customers with the service of producing PCB,
Soldering Circuit Boards, SMT Soldering and DIP Soldering. What's more,
customer can issue the testing mode by yourself. And ICStation will do
the testing and ship the tested products to customer after production.
How to process the PCB service order?
First customers should email ICStation the PCB parameters
and PCB materials as below before getting the
quotation.
1. PCB
parameters
- PCB Qty
- PCB Layer
- PCB
Thickness
- PCB Size
- PCB Color
2.PCB
material (Gerber file)
- Silk Top:
pcbname.GTO
- Top Layer:
pcbname.GTL
- Bottom
Layer: pcbname.GBL
- Solder Mask
Bottom: pcbname.GBS
- Top Paste:
pcbname.GTP
- Board
Outline: pcbname.GKO
- Drill
Drawing: pcbname.TXT
- Silk
Bottom: pcbname.GBO (if your PCB has legend elements and text at the
bottom)
Then
ICStation will offer customer a quotation accordingly.
Third, ICStation will process the order as below after confirmation on
the price.
- Customer should pay ICStation for the fee at first
- ICStation pass the material to the manufacturer after the payment is
received
- Manufacturer will provide ICStation with the PCB in 7-10 working days
- ICStation will help to ship the PCB to customer once get them from
manufacturer
|
