100s Time Delay Relay Module AC 220V Adjustable Device Power ON Protector
$3.49$4.9930%
00d : 00h : 00m : 00s
Item ID: 13540
Product Details
Description:
It is a AC 220V power ON delay relay module. Used for device boot protection.
Parameters:
1>.Item Name:AC 220V 100s Delay Relay Module
2>.Model:QF1022-B-100S
3>.Work voltage:AC 220V
4>.Adjustment accuracy:1second
5>.Delay time:1~100second
6>.Load:AC 250V 10A or DC 30V 10A
7>.Error value:2%
8>.Work Temperature:-40℃~85℃
9>.Work Humidity:0%~95%RH
10>.Size:58*43*22mm
Funciton:
Power ON->Delay->Relay ON after delay->Keep ON.
Note:
It is a relay output and just like a switch, so it can not output voltage.
User need connect power supply at output terminal for load.
Application:
1>.Device delay protection
2>.Power on protection
3>.Voltage stability regulator
4>.Home Appliances
5>.Lighting delay modification
6>.Factory equipment delay control
Package:
1pcs AC 220V 100s Delay Relay Module
