Battery Charge Controller OverDischarge Undervoltage Protection Module Automatic Power Charger Module for 12V Battery
Product Details
Parameters:
| No. | Parameter | Value |
| 1 | Product name | Battery under voltage and charging protection module |
| 2 | Product model | X802 |
| 3 | Applicable battery | 12V battery |
| 4 | Output mode | Switch |
| 5 | Voltage error | ± 0.1V |
| 6 | Product load | 10A |
| 7 | Voltage regulation | potentiometer |
| 8 | Product size | About (L)60mm* (W)30mm* (H)18mm |
| 9 | Size | About 42mm (2 hole * 3mm) |
| 10 | Product weight | About 24g |
| 11 | Product packaging | Antistatic bag |
Potentiometer Adjustment:
1>. Adjust the under-voltage voltage load off voltage:
Clockwise adjustment the voltage step up and counterclockwise step down.
Turning half lap clockwise is up 0.4V(Do not exceed two laps adjustment for 12V battery.), while turning half lap counterclockwise is down 0.4V(Do not exceed two laps adjustment for 12V battery.).
2>. Adjust Over-voltage voltage charging off voltage:
Clockwise adjustment the voltage step down and counterclockwise step up.
Turning half lap clockwise is up 0.5V(Do not exceed one lap adjustment for 12V battery.), while turning half lap counterclockwise is down 0.5V(Do not exceed three laps adjustment for 12V battery.).
Note:
When you adjust the potentiometer, please remember the number of laps.
Wiring Instruction:
Product Details:
