ESP32-CAM ESP32 5V WIFI Bluetooth-compatible Development Board with OV2640 Camera Module

$7.66
$11.7935%
Quantity5+15+30+50+
Price$6.70$6.60$6.50$6.45
00d : 00h : 00m : 00s
Item ID: GY16338

Product Details

1.Description:
  The ESP32-CAM has a very competitive small-size camera module that can operate independently as a minimum system, measuring only 27*40.5*4.5mm, with deep sleep current and a minimum of 6mA.

  ESP-32CAM can be widely used in various IoT applications. It is suitable for home smart devices, industrial wireless control, wireless monitoring, QR wireless identification, wireless positioning system signals and other IoT applications. It is an ideal solution for IoT applications.

  ESP-32CAM is packaged in DIP and can be directly plugged into the backplane for quick production. It provides customers with a highly reliable connection method and is convenient for use in various IoT hardware terminals.

2.Feature:
  1>.Ultra-small 802.11b/g/n Wi-Fi + BT/BLE SoC module
  2>.Low-power dual-core 32-bit CPU for application processors
  3>.Up to 240MHz, up to 600 DMIPS
  4>.Built-in 520 KB SRAM, external 4M PSRAM
  5>.Supports interfaces such as UART/SPI/I2C/PWM/ADC/DAC
  6>.Support OV2640 and OV7670 cameras with built-in flash
  7>.Support for images WiFI upload
  8>.Support TF card
  9>.Support multiple sleep modes
  10>.Embedded Lwip and FreeRTOS
  11>.Support STA/AP/STA+AP working mode
  12>.Support Smart Config/AirKiss One-click distribution network
  13>.Support for serial local upgrade and remote firmware upgrade (FOTA)

3.Parameter:
  1>.Model: ESP32 CAM
  2>.Work Voltage:DC 5V
  3>.Work Current:2A
  4>.Image Format:JPEG(Just for OV2640),BMP,GRAYSCALE
  5>.Work Frequency:2412~2484MHz
  6>.WIFI Standard:802.11/b/g/n/d/e/i/k/r
  7>.Work Temperature:-25℃~85℃
  8>.Work Humidity:5%~95%RH
  9>.Size:40*27*17mm

4.Note:
  This product contains the OV2640 Camera Module. If you need to use the OV7670 camera, please purchase it separately.

5.Package:
  1>.1pcs ESP32-CAM Module
  2>.1pcs Camera Module OV2640
