ILI9225 2.0 Inch SPI Serial Port TFT LCD Display Module SPI Interface 176x220 Resolution 4 IO Support for Arduino
$5.93$6.5910% (only 0 pcs )
00d : 00h : 00m : 00s
Item ID: 11099
Product Details
Product Introduction:
1.Size:2.0 inch SPI seial bus
2.Resolution:176*220
3.Driving IC:ILI9225
Features:
1.Support Arduino MCU direct insertion,don't need any connections.
2.Integrated stabilivolt IC,support 5V or 3.3V power supply.
3.Compatible with 5V/3.3V IO level,support MCU IO connections.
4.Integrated backlight control circuit,can control on/off or PWM dimming.
5.Integrated SD card expansion circuit
6.Preserve SPI FLASH word circuit,easy tot expand applications.
Warning: Considering respect the copyright of our partners, it is not allowed to use the following pictures and videos in any other store without approval. We are not responsible for any complaints if you used them from our website arbitrarily!!!
I. Tested by ICStation's Outstanding Partner Hugatry's HackVlog:
Learn More Details in the Video:
(The language in the video is English)
(The language in the video is English)
II. Tested by ICStation's Outstanding Partner adrirobot:
1>. Connection with slow SPI connection:
2>. Connection with fast SPI connection:
3>. Using the display as a digital picture frame:
4>. Realization of a digital clock:
Learn More Details in the Link and the Video:
https://www.adrirobot.it/display_tft/Display_tft_2_Inch_176x220_SPI.htm
(The language in the video is Italian)
III. Tested by ICStation's Outstanding Partner Maker Tutor:
Learn More Details in the Video:
Tested with the Lua Nodemcu WIFI Networ IOT Development Board
.jpg)
.png)
.png)
.png)
Learn More Details in the Video:
