DIY Kits HIFI 6J1 Electronic Tube Hybrid Power Amplifier Board Headphones Power Amplifiers LM1875T DIY Amplifier Module 20W

$12.34
$18.9935%
Quantity5+10+30+
Price$13.20$12.90$12.50
00d : 00h : 00m : 00s
Item ID: 12008

Product Details

Product Introduction:
1.Power Supply Voltage: defaults double AC 18V/3A, power more than 60W (the maximum voltage should be no more than double AC 19V, and it should be no less than 18V; or the digital tube will be off, and the voice will get distorted; if you want to use AC 12V, you need to modify lamp filament buck resistance 2.2 ohm; then the amplifier output power will be relatively low).
2.Headphone amplifier/pre-output: amplification times is 0.8
Im1875t amplifier output power: typical 20W (max 30W)
3.Loudspeaker impedance: 4-8 ohm
4.Total harmonic distortion: <0.04%
5.Signal noise ratio: 105dB
6.Frequency response: 14Hz-100KHz

Component List:

NO. Components Silk Screen Parameter QTY
1 Metal Film Resistor R1,R3,R10,R13,R17,R18,R20,R21 4.7K 8
2 Metal Film Resistor R2,R4,R30,R31 1K 4
3 Metal Film Resistor R5-R8 47ohm 4
4 Metal Film Resistor R22,R23 56K 2
5 Metal Film Resistor R11,R14 470K 2
6 Metal Film Resistor R12,R15 200ohm 2
7 Metal Film Resistor R9 3W 47ohm 1
8 Metal Film Resistor R16,R19 100K 2
9 Metal Film Resistor R24,R26,R27,R32 22K 4
10 Metal Film Resistor R25,R28 10ohm 2
11 Electrolytic Capacitor C13,C14 47uf 10V 2
12 Electrolytic Capacitor C1-C4 2200uf 25V 4
13 Electrolytic Capacitor C5-C8 470uf 35V 4
14 Film Capacitor C15,C16 0.1uf 50V 2
15 Film Capacitor C9-C12 1uf 50V 4
16 LM1875T U1,U2 TO-220-5 2
17 D667 Transistor Q1,Q4 TO-92 2
18 D647 Transistor Q2,Q3 TO-92 2
19 Audio Socket J3,J4 3.5mm 2
20 Terminal J1,J2 KF301-2P 2
21 Terminal J5 KF301-3P 1
22 LED D1,D2 3mm 2
23 Rectifier Bridge P1 KBJ608 1
24 Potentiometer RP 50K 1
25 Screw   M3*5mm 2
26 Screw   M3*6mm 2
27 Isolation sheet   M3 2
28 Heat Sink     1
29 Thermal Grease     1
30 Nut     1
31 6J1 Electronic Tube     2
32 6J1 Socket     2
33 T0-220 Insulation film     2
34 PCB     1

Finished Product Picture:

Please Download the Diagram here:



I. Tested by ICStation's Outstanding Partner arduinoLab:



Learn More Details in Below Video:
(The language in the video is Russian)


II. Tested by ICStation's Outstanding Partner 12voltvids:

Learn More Details in the Video:
(The language in the video is English)


III. Tested by ICStation's Outstanding Partner Mundo Electrónica:

Learn More Details in the Video:
(The language in the video is Spanish)

Customer Reviews (5)

  • By Lindsey Lewis2022-04-26 09:36:04

    Amp works well, but has narrow mains band. I am in USA and mains where I live are 122 VAC. Toroid expects 110 vac but gets 122 and outputs 22 vac. So rectifier then puts out 27 VDC. Blew 2200 uF 25VDC caps right off. Then I installed 4x 2200uF 50 VDC rated Low ESR caps instead. Put on underneath side of circuit board to make them fit. Then I installed a 62 ohm 5 watt resistor. Heat sink then runs pretty consistent at 69 or 70 degrees C. Probably needs slow fan or bigger heat sink.
  • By Henny Beekman2022-03-27 23:23:47

    Nice amplifier for my STAX Electrostatic headphone SX34. Amplifier has enough power to drive the transformator for de elctrotatic Headphone. Sounds super.

  • By Tyler Mitchell2020-03-15 13:18:20

    Great project! Could use a little more protective packaging and the heat sink tears the bag, but package arrived in good writing order. Please advise if this input power transformer is suitable - it's hard to find and we need English instructions, though board is very clearly labeled good job :) https://www.newark.com/triad-magnetics/vpp36-1560/power-transformer/dp/37B9213
  • By Charles Tyler2018-07-21 04:41:02

    I bought this kit months ago and I am having trouble finding a transformer for it, so you guys sell one? or can you put a link to one that will work? Thanks
  • By Larry Zwierski2017-08-23 20:41:49

    Very nice kits, all complete. The Chinese manual is very good to understand. Anyway it's easy.
