DIY SMD Rotating LED Components Soldering Practice Board Skill Training DIY Kit
| Quantity | 5+ | 10+ | 30+ | 50+ |
| Price | $2.60 | $2.30 | $2.10 | $1.59 |
Product Details
Product Introduction:
1.Size: 90*60mm
2.Thickness:1.6mm
3.Flow Water Lamp Circuit: CD4017, NE888, LED; after correct connnection, it will operate
4.Operating Voltage: 3-12V
5. Board material: international standard sheet, all tin pad, high strength fire drop material, can be repeated disassembly.
6. PCB board design is reasonable, are commonly used in the SMD components.
7. The left and right of the three components are used to practice welding, each column with a test point.
8. The middle of the circular circuit for the water lamp circuit, by the CD4017, NE555, light-emitting diodes, welding power can work.
9. The circuit is also used on the back, a ruler to facilitate the measurement of components. There are examples of PCB conductors to facilitate the use of PCB design.
10. This kit contains all the elements of the following photos.
Packing List:
| No. | Name | Parameter | QTY |
| 1 | 1206 Resistor | Random | 12 |
| 2 | 0805 Capacitor | Random | 12 |
| 3 | 0805 Resistor | Random | 12 |
| 4 | 0603 Resistor | Random | 14 |
| 5 | 0603 Capacitor | Random | 14 |
| 6 | 0402 Capacitor | Random | 14 |
| 7 | 0805 Resistor | 1K ohm | 15 |
| 8 | LED | 11 | |
| 9 | LED | 4 | |
| 10 | Triode | J3Y | 4 |
| 11 | Diode | 4148 | 4 |
| 12 | 0805 Resistor | 10K ohm | 5 |
| 13 | 0805 Resistor | 2M ohm | 1 |
| 14 | 0805 Capacitor | 0.1uF | 2 |
| 15 | IC | NE555 | 1 |
| 16 | IC | CD4017 | 1 |
Finished Product Picture:
Circuit Picture:
