DIY Kit C51 Intelligent Vehicle Obstacle Avoidance Tracking Car, Smart Robot Car Kit School Competition Electronic Projects for Students and DIYers Learn to Solder

$16.24
$24.9935%
Quantity3+5+10+
Price$17.20$17.00$16.50
00d : 00h : 00m : 00s
Item ID: 13029

Product Details

Parameters:
Note: Package does NOT contain battery.

No. Parameter Value
1 Name Intelligent vehicle obstacle tracking car
2 Voltage DC 6V
3 Material The PCB is with high quality,which thick 3mm;
wheels are rubber material
4 Features Simple mechanical structure, easy to install.
The two deceleration DC motors turn flexibly and have good directivity.
Two motor drives, horsepower.
The chassis is large and stable and easy to expand.
5 Purpose Car tracking, infrared obstacle avoidance car,
car maze, object tracking function.


Function:
1>. The range of infrared tracking module to realize intelligent tracking (go black or white)
2>. The two pairs of infrared reflections in front of the front can realize intelligent collision avoidance (obstacle avoidance) function and robot maze. The on-board obstacle avoidance processing chip makes the obstacle avoidance distance farther.
3>. The intelligent robot maze experiment was realized by two pairs of infrared reflection probes in front of the front.
4>. The intelligent robot object tracking function is realized by the two pairs of infrared reflection probes in front and right.
5>. The infrared receiving diode is changed to light sensitivity, which increases the daytime and night recognition function for the robot and can be used as a light finding robot. (search for light and infrared barrier can not be used simultaneously).



Installation Guide:


Component List:

No. Component Name PCB Marker Parameter QTY
1 Ceramic Capacitor C2-C4,C7 0.1uf 104 4
2 Ceramic Capacitor C8,C6 30pf 2
3 LED 3mm D3,D5 Green 2
4 LED 3mm D5 Red 1
5 L293D IC1 DIP-16 1
6 IC Socket IC1 DIP-16 1
7 STC89C52 IC2 DIP-40 1
8 IC Socket IC2 DIP-40 1
9 Metal Film Resistor R2,R3 10K 2
10 Metal Film Resistor R8,R14 1.5K 2
11 Network Resistor RX1 10K 1
12 Button S2 6*6*5mm 1
13 Crystal Z1 12MHz 1
14 Electrolytic Capacitor C1 10V 1000uF 1
15 LED 3mm D1,D2 Green 2
16 Infrared Transmitter V2,V4,V8,V9 3mm 4
17 Infrared Receiver V3,V5,V6,V7 3mm 4
18 LM393 IC3 DIP-8 1
19 IC Socket IC3 DIP-8 1
20 Metal Film Resistor R6,R7,R10,R11 10K 4
21 Metal Film Resistor R12,R13,R15 220ohm 3
22 Metal Film Resistor R16,R18 15K 2
23 Switch S1   1
24 Potentiometer W1,W2 10K 2
25 Male Pin P1-P3 4P 3
26 Male Pin P5,P7 3P 2
27 Sensor PCB   43*65mm 1
28 Main PCB   77*170mm 1
29 Motor     2
30 Battery Box   AA*4 2
31 Cable   7cm 2
32 Non-slip ring     2
33 Wheel   40mm 4
34 Axle   2*120mm 1
35 Motor Fixed seat     6
36 M3 Nut     7
37 M3*8mm Screw     3
38 M3*25mm Screw     4
39 Heat shrink tube   5cm 1
40 Motor Fixed Screw     2
41 Loader     1
42 Cable     4

Finished Product:



Product Size:



Tested by ICStation's Outstanding Partner ElectroTodos:

Learn More Details in the Video:

Customer Reviews (1)

  • By Vasily Dyachenko2020-01-25 15:39:01

    Hello. I have received the order DIY Kit C51 Intelligent Vehicle Obstacle Avoidance Tracking Kit Intelligent Car DIY Smart Car Module. But, the Manual http://attach01.oss-us-west-1.aliyuncs.com/IC/DIY-Manual/13029.pdf is not correct ! These is no information on the last two pages. Ask you to sent the correct Manual. Thanks!
