MAX31865 Resistance Temperature Detector RTD Sensitivity Thermistor to Digital Output Converter PT100 to PT1000
$7.99 (only 1 pcs )
Item ID: GY19780
Product Details
1.Description:
MAX31865 is an easy-to-use thermistor-to-digital output converter,optimized for platinum resistance temperature detectors.
2.Feature:
1).Its external resistance sets the RTD sensitivity, and the high-precision delta-sigma ADC converts the ratio of the RTD resistance to the reference resistance into a digital output.
2).The MAX31865 input has overvoltage protection up to +/-45V, provide configurable RTD and cable open-circuit and short-circuit condition detection.
3).Support integrated fault detection and increases system stability.
3.Parameter:
1).Product Name:MAX31865 Converter
2).Supply Voltage:DC 3.3V
3).Interface:SPI compatible interface
4).Temperature Resolution:0.03125°C
5).Conversion Time:21ms
6).Work Temperature:-25℃~85℃
7).Work Humidity:5%~95%RH
8).Size:25*27*3mm
4.Package:
1).1pcs MAX31865 Converter
2).2pcs Terminal
3).1pcs Pin
