RC522 RFID IC Card Reader Writer Module 13.56MHz 3.3V SPI Module
Product Details
1.Description:
1>.Adopting RC522 low voltage, small size non-contact read and write card chip;
2>.Can support Mifare1 S50, Mifare1 S70, Mifare Light, Mifare UltraLight, and Mifare Pro;
3>.Can be directly loaded into various card reader molds;
4>.It can directly communicate with any CPU motherboard of the user through the SPI interface;
5>.It has the characteristics of easy to use, high reliability, small size, and long card reading distance;
6>.Can help customers conveniently and quickly apply non-contact cards to the system.
2.Parameter:
1>.Work Current : 13-26mA / DC 3.3V
2>.Idle Current : 10-13mA / DC 3.3V
3>.Sleep current: <80uA
4>.Peak current: <30mA
5>.Operating Frequency: 13.56MHz
6>.Supported card types: mifare1 S50、mifare1 S70、mifare UltraLight、mifare Pro、mifare Desfire
7>.Environmental Operating temperature: -20℃~85℃
8>.Environment Storage temperature: -40~85℃
9>.Relative Humidity: 5%~95%
10>.Size: 37.5*33mm
3.Package
1>.1pcs RFID-RC522 module;
2>.1pcs Standard S50 Blank Card;
3>.1pcs S50 shaped cards (as shown keychain shape);
4>.1pcs Straight row pin
5>.1pcs Curved row pin
