Home > Power Module > Charger Module > Solar Charging Circuit Board Mobile Power Boost Module 5V 1A 2A Charger Step UP Module

Solar Charging Circuit Board Mobile Power Boost Module 5V 1A 2A Charger Step UP Module

14047
5 9
$5.29 $3.70 (only 0 pcs )
Contact us for wholesale price
Time Remaining:

Sold out


Parameter:
  1>.Input charging voltage: DC 5V 1A
  2>.Input battery voltage:DC 3.7V-4.2V Polymer Rechargeable Lithium Battery
  3>.Solar panel charging voltage:DC 4.5V-5.8V
  4>.Output channel:2CH
  5>.Output voltage:5V2A/5V1A
  6>.Operating Temperature:-20℃~85℃
  7>.Operating Humidity:5%~95%RH
  8>.Module Size:69*21*6mm

Feature:
  1>.Support solar panel charging
  2>.Support discharge while charging
  3>.Support dual USB output
  4>.Support backflow protection

Button Function:
  1>.Keep press more than 5second to wake up or turn OFF module
  2>.Double click to turn ON/OFF LED flashlight

Note:
  1>.2A is the max output current.It is not a constant current power module.Its output current change by load!It can not keep output 2A fixed.
  2>.Old and new batteries can not be mixed.
  3>.The solar panel charging current is just about 50mA.So the solar charging speed is very slow which can only play a supporting role.
  4>.The battery cannot be reversed, otherwise the module will be damaged.
  5>.Please check the battery voltage first. If the battery voltage is lower than 3V, the module will not work properly.
  6>.Please input from Micro USB socket to activation module at first before connect battery.
