ICStation DC to DC Auto Converter Step Up and Down Boost Converter/Buck Converter Module DC 3.5V-28V to DC 1.25V-26V
$2.50$4.9950%
| Quantity | 10+ | 30+ | 50+ | 100+ |
| Price | $3.35 | $3.20 | $3.10 | $2.99 |
00d : 00h : 00m : 00s
Item ID: 3231
Product Details
Description:
This module can realize the function that input voltage within a certain range, and output voltage automatically (it will not be affected by input voltage).
It can be used as step up and down power module that user can adjust the power more Convenient.
Parameters:
- Input voltage:3.5-28V
- Input current:1A
- Output voltage:1.25-26V
- Output current:1A
Maximum Rating:
- Input voltage:32V
- Input current:3A
- Output voltage:32V
- Output current:3A
PCB Size: 60mm*37mm (L*W)
Notes:
Due to the low frequency of switch, the inductance will make some noise when the current is high. But it'll not affect the usage.
Module Details:
Download the document from here:
Tested by ICStation's Outstanding Partner ELECTROJUANYU:
Please Kindly See the Voltage Changes as Followings:
Learn More Details in the Video:
(The language in the video is Spanish)
