5S 3.7V Polymer Lithium-Ion Battery 18.5V 50A Charging Protector Balanced Function Board
$6.99$9.9930%
00d : 00h : 00m : 00s
Item ID: 13590
Product Details
Parameters:
1>.Overcharge protection voltage:4.25V+/-0.025V
2>.Overcharge release voltage:4.15V+/-0.05V
3>.Overcharge protection delay:1S+/-200mS
4>.Over-discharge protection voltage:2.7V+/-0.05V
5>.Over discharge release voltage:3.0V+/-0.1V
6>.Over-discharge protection delay:1S+/-200mS
7>.Discharge overcurrent protection:70A
8>.Discharge overcurrent protection delay:100ms+/-50mS
9>.Short circuit protection:Yes
10>.Short circuit protection delay:250uS+/-50uS
11>.Short circuit protection recovery method:Disconnect load recovery output
12>.Discharge current:50A
13>.Charging current:50A
14>.Balanced function:Yes
15>.Balanced turn-on voltage:4.18+/-0.025V
16>.Balanced current:55mA
17>.Wire break protection:Yes
18>.Temperature protection:Yes(User need install 10K NTC sensor additional)
19>.Charging low temperature protection:-7℃
20>.Charging high temperature protection:50℃
21>.High temperature protection:70℃
22>.Size:60*37*7.6mm
Package:
1pcs Charging Protector
1pcs 6pin 20cm wire
Tested by ICStation's Outstanding Partner CarlosVolt Tutoriales:
Learn More Details in the Video:
(The language in the video is English)
(The language in the video is English)
