FM Wireless Microphone DIY Kits FM Radio Electronic Training Suite DIY Module DC 1.5-9V 1-6mA No Battery

10645
5 1
$2.79 $1.95
Quantity10+50+100+150+200+
Price$1.99$1.89$1.70$1.65$1.50
Contact us for wholesale price
Time Remaining:
- OR - - OR - Add to Wish List

Simple DIY FM Wireless Microphone Electronic Kit

Support Wholesale! Free Express DHL Shipping for Order from $200.

Product Introduction:
1.Operating Voltage:DC 1.5V-9V
2.Operating Current:1mA-6mA
3.Operating Frequency:87-108
4.Board Size:22*52mm
5.Transmitting Distance:10-30m

Packing List:

Name Parameter Mark Number
Metal Film Resistor 4.7k R1,R2 2
Metal Film Resistor 47k R3 1
Metal Film Resistor 10k R5 1
Metal Film Resistor 330R R6 1
Ceramic Capacitor 104 C1 1
Ceramic Capacitor 102 C2 1
Ceramic Capacitor 15P C5 1
Ceramic Capacitor 24P C4,C6 2
Ceramic Capacitor 30P C7 1
Ceramic Capacitor 201 C8 1
Switch   J2 1
CR2032 Case   J1 1
LED   D1 1
Microphone   MIC 1
Inductance   L1 1
S9018   Q1 1
