2.Operating Voltage: 4.5-5V
3.PCB Thickness: 1.6mm
4.Appearance Size: 91.4*60mm
|NO.||Component Name||PCB Marker||Parameter||QTY||Remarks|
|1||Resistor||0805||SMD 0805||10||Just for practice|
|2||Resistor||0603||SMD 0603||14||Just for practice|
|3||Resistor||0402||SMD 0402||12||Just for practice|
|4||Capacitor||0805||SMD 0805||10||Just for practice|
|5||Capacitor||0603||SMD 0603||14||Just for practice|
|6||Diode||1206||SMD 1206||6||Just for practice|
|7||Transistor||SOT-23||SOT-23||6||Just for practice|
|8||Resistor||8P4R 0603||SMD 0603||6||Just for practice|
|9||IC||SO-8||SOP-8||1||Just for practice|
|10||IC||SO-16||SOP-16||1||Just for practice|
|11||IC||QFP44||QFP-44||1||Just for practice|
|12||SMD 0805 Resistor||R1,R3||1.2K||2|
|13||SMD 0805 Resistor||R2||470K||1|
|14||SMD 0805 Capacitor||C3||10nF||1|
|15||SMD 0805 Capacitor||C4||100nF||1|
|19||SMD 3216 Capacitor||C1-C2||2|
NOTE 1: Some components only for practice without o actual function. Can be installed in any suitable location.
NOTE 2: The components within circle can not be free to install.
NOTE 3: Users can complete the installation by PCB silk screen and components list.
