High Voltage Generator 80KV 2cm Super Arc 6V-12V Inverter Pulse High-Voltage Generator

8135
5 9
$4.49 $3.28
Contact us for wholesale price
Time Remaining:
- OR - - OR - Add to Wish List

Cheaper Buy Together

$3.28-6%Bundled Price:$3.08
NOTE:
1. Avoid power on when No load.You must adjust the appropriate distance for high-voltage terminal before power on.The longer Arcing distance,the higher input voltage and battery capacity.
2. It is prohibited exceed the maximum arcing distance.Otherwise,Energy can not be released due to high pressure, easily damaged modules.
3. Can not work long time.
4. Please connect it to metal after test to release surplus energy!
5. It is a high-pressure arc generator and not high temperature arc generator so it can not ignite paper or cigarette

Description:
1. Module Model: MCF-12-2
2. Physical Volume: 42*22*17.5mm
3. Input voltage: 6V-12V
4. Input Current: 0.5A-1A
5. Input line length: about 11cm
6. High pressure type: pulsed DC type
7. Output voltage: about 80KV (please pay attention to safety when used)
8. High voltage poles discharge distance: 1.5cm-2cm
9. About Power supply:recommend 6V and above 2000mAh for best results

Feature:
1. High voltage pulse current output
2. Small size
3. high efficiency
4. Simple peripheral circuits(just need button and battery)

Application:
1. Science experiments
2. Electronic Instruments
3. Ionizer
4. DIY Kit

Input power:
You can use two 3.7V lithium batteries or three in series, such as 18650 batteries, idle mobile phone batteries (with the protection board removed, the recommended capacity is more than 2000mAh) or nickel-cadmium/nickel-metal hydride battery packs, 6V or 12V lead-acid batteries, etc.

How to use the product:
The module is divided into input terminal and output terminal. The red and green (white) wires are the input terminals, and the red positive and green (white) wires are the input terminals. Two thick high-voltage wires with the same color are the input terminals. Fix the proper arc distance of the output terminal. , The input terminal can be connected to the battery to generate high voltage or high temperature arc.

This module is a finished module of high-voltage inverter, transformer/booster for scientific small production. After inputting DC6V-12V voltage at the input end, you can get a DC high voltage of about tens of thousands of volts at the output end. Can be used as a high-voltage source for general experiments, electronic instruments, negative ion generators, and small scientific production.

The module is made using the principle of Tesla coil, output high-voltage pulse current, small size, high efficiency.The peripheral circuit is simple (just connect the switch, the battery can be) discharge intensity is violent.
