ICStation DC to DC Step Up Module Boost Converter Power Supply Module DIY Kit DC 5V to DC 12V

4151
5 9
$1.89 $1.55
Time Remaining:
- OR - Add to Wish List

Cheaper Buy Together

$3.03-6%Bundled Price:$2.85
Description

DC 5V to DC 12V booster module

5V to 12V booster module is based on MC34063 chip booster module, can realize the input 5V voltage, stable output of 12 v voltage.

A. Principle
This circuit mainly include filter capacitance, booster chip MC34063 and resistance, lose Into the voltage through the filter capacitor, link to booster chip MC34063, MC34063 the input voltage booster to the 12V output, after electrolytic capacitor filter, stable output of 12V voltage.

B. Electrical Characteristics
The input voltage: 4.5 ~ 5.5V
Output voltage: 11.5 ~ 12.5V
The maximum output current: 60mA
PCB size: 6.5 * 2.5 cm

C. Schematic Diagram

D. List of Components

Number

Component

Label

Footprint

Value

Number

1

5mm red LED

D2

LED_5



1

2

1N5819

D1

TO-41



1

3

Ceramics capacitors

C2,C4

RAD-0.2

104

2

4

Ceramics capacitors

C3

RAD-0.1

101

1

5

Electrolytic capacitor 25V/47UF

C1

RB.1/.2

47UF

1

6

Resistance

R1

AXIAL-0.4

200R

1

7

Resistance

R2

AXIAL-0.4

1R

1

8

Resistance

R3

AXIAL-0.4

10K

1

9

Resistance

R4

AXIAL-0.4

1.2K

1

10

Resistance

R5

AXIAL-0.4

4.7K

1

11

Terminal

J1,J2

KF301-2P



2

12

MC34063





1

13

8P IC seat





1

14

150uH inductance

L1

AXIAL-0.4

150UH

1
