US Plug 220V DIY Kit LM317 Adjustable DC Power Supply Board Voltage Regulator Module Kits with Acrylic Case

12518
4 1
$15.59 $10.91
Contact us for wholesale price
Time Remaining:
- OR - - OR - Add to Wish List

Cheaper Buy Together

$24.21-6%Bundled Price:$22.75
Description:
LM317 adjustable DC power supply board.

Features:
1>. This is a particularly practical power pack that switches the voltage display or voltmeter function freely by twisting the voltage knob!
2>. The output power range is wide: 1..25V-14..5V is adjustable, and the output voltage is larger than the common power supply
3>. With voltage measuring function: can test the voltage of any point of the external module.
4>. Optional 2mm thick acrylic shell, our shell opening accurate, beautiful and practical, it is recommended matching.

Tips:
This is the delivery suite of parts, you need welding installation. SCM has written procedures, successfully tested.

Parameter:
NO. Parameter Value
1 Name LM317 adjustable DC regulated power supply kit
2 Shell size 116*73*55mm
3 PCB size 77*67mm
4 Shell color Acrylic transparent shell
5 Product weight Total weight 290g
6 Plug Type US Plug
7 Power Supply Mode AC 220V
8 Power supply 2W (12V transformer) can configure large power by itself
9 Output voltage 1.25-14.5 regulated output is continuously adjustable
10 Data One of the circuit installation drawings


Product Details:

Component Listing:

NO. Component Name PCB Marker Parameter QTY
1 Metal Film Resistor R1 240ohm 1
2 Metal Film Resistor R0,R2,R3 1K 3
3 Metal Film Resistor R4 100K 1
4 Potentiometer R5 100K 1
5 Metal Film Resistor R6 10K 1
6 Potentiometer Rp1 10K 1
7 Diode D1,D2 1N4148 2
8 LM317 U1 TO-220 1
9 Terminals P1 2P 1
10 IC Socket U2 DIP-14 1
11 CD4069 U2 DIP-14 1
12 Diode D3,D4,D5,D6 1N4007 4
13 Blue LED D7 5mm 1
14 Yellow LED D8 5mm 1
15 Red LED D9 5mm 1
16 Green LED D10 5mm 1
17 Electrolytic Capacitor C1,C4 470uF 2
18 Ceramic Capacitor C2,C3 0.1uF 2
19 Electrolytic Capacitor C5,C6 10uF 2
20 Transistor S9014 Q1 TO-92 1
21 Active Buzzer LS1 5V 1
22 Terminals P2 3P 1
23 Heat sink   25*35*15mm 1
24 Heat shrink tube   2MM 1
25 220V power cord   250V 5A 1
26 Potentiometer knob     1
27 Digital voltmeter     1
28 Transformer   12V 1
29 Screw   M3*6 7
30 Nuts   M3 6
31 Nylon column   M3*5 2
32 Screw   M1.7*10 10
33 Nuts   M1.7 10
34 PCB   63*73mm 1
35 Acrylic shell     1
36 Power Cable     1
