SPI Interface Converter PinBoard 16Bit I/O Extension Board Module MCP23S17-E/SS for Arduino

13075
5 9
$4.75 $3.52
Time Remaining:
- OR - Add to Wish List

Description:
This module is the 16 IO extension module of the SPI interface, and uses the MCP23S17 chip of MicroChip. The chip is fully functional, each IO can be configured as input or output arbitrarily, and it can be used for color weaving to use pull-up resistors, and configured as input sub IO can enable interrupt function. The IO interface has a strong driving capacity, and the current and current can reach 25mA.
    MCP23S17 is a high-speed SPI interface, up to 10MHz. The chip has 3 address pins and can set 8 different addresses, so 8 modules can be connected through two IIC buses to achieve up to 128 IO extensions.

Parameters:

No. Parameter Value
1 Working voltage 3.0-5.5V
2 Drive chip MCP 23S17
3 Number of IO 16 (input, output, interruption)
4 Drive current 25mA
5 SPI frequency < 10MHz
6 Working temperature -40 Celsius to 85 Celsius
7 Chip level Industrial grade
8 Parallel multiple Up to 8
9 Driver Arduino Library
10 Module size About 65mm*19mm


Wiring Instruction:
Picture One:




Picture Two:




Picture Three:




Drive Instance:




Package List:

No. Items Qty Unit Remark
1 MCP23S17 SPI IO extension module 1 pcs Without soldering
2 Straight pin 1*20 Pin
3 Curved pin 1*20 Pin
4 Double row straight pin 2*7 Pin
5 Double row curved needle 2*7 Pin
