Mini Active Loudspeaker Suite Football Shape DIY Module for Funny DIY Kit Experimental Teaching Kit

9922
5 1
$8.99 $6.47 (only 0 pcs )
Contact us for wholesale price
Time Remaining:

Sold out


Note: Due to some reasons, this product is out of stock recently. If you make bulk orders, please feel free to contact our customer service orders@icstation.com. Bulk orders will be realized. Please kindly noted. :)


Component List:

Components Parameter Quantity
Resistor 4.7 ohm 2
Resistor 820 ohm 1
Resistor 2K 2
Resistor 3.9K 2
Ceramic Capacitor 104P 4
Electrolytic Capacitor 100uF/6.3V 2
Electrolytic Capacitor 220uF/10V 3
Integrated Circuit TDA2822 1
LED Green 1
DC Socket DC 25 1
Disk Potentiometer 50K 1
Toggle Switch SK12D07VG3 1
Wire D0.8 60MM Red 1
Wire D0.8 60MM Black 1
Colorful Wire 120MM Red Black 2
Audio Wire 320MM 1
Front Shell   1
Battery Case   1
Battery Back Cover   1
Left Audio Front Shell   1
Left Audio Back Shell   1
Right Audio Front Shell   1
Right Audio Back Shell   1
Toggle Button   1
Base Socket   1
Loudspeaker 2W 4 ohm 2
Spongy Cushion 20*20*8MM 2
Battery Shrapnel   9
Screw 6PA 16
PCB   1


Finished Product for reference:



Connection Diagram:
