Home > Sensor Module > Thermistor Sensor Module > PI Heating Thin Film Polyimide Heating Plate Panel 25x50mm 12V 7W

PI Heating Thin Film Polyimide Heating Plate Panel 25x50mm 12V 7W

9887
5 9
$4.99 $3.49
Quantity10+30+50+80+
Price$3.35$3.20$2.95$2.70
Contact us for wholesale price
Time Remaining:
- OR - - OR - Add to Wish List
Product Introduction:
Polyimide heater film uses polyimide as insulator outside, and the thermo foil as electric heating element inside, formation through high temperature and high pressure heat sealing process.
Extremely thin, lightweight and flexible, polyimide heaters can quickly provide heat to where it is needed widely used in the electronics manufacturing, medical devices, scientific instruments.

Polyimide film has excellent dielectric strength, excellent resistance to electric intensity, perfect heat transfer efficiency, and great resistance stability. Safe to use with stable performance.
Note: Heating films can not control the temperature itself. You can use it with a temperature controller. Equipped with self-adhesive can be fixed on the item surface easily.

Parameter:
1.Name:heating film
2.Size:25*50mm / 0.98 X 1.97inch (L*W)
3.Working Voltage:DC 12V
4.Power:7W

Performance Diameter:
1.Insulation Thermal Conduction Layer: polyimide film
2.Thickness:<0.2mm
3.Operating Temperature:-190℃~205℃
4.Power Deviation:<+/-5%
5.Lead Wire Tensible Strength:>5N
6.Gun Adhesive Force:>40N/100mm

Features:
1.Fast Preheating Speed
2.Long Using Life
3.Space Saving

Applications:
1.Scientific Analyse Instrument:such as provide constant temperature source for thermal conductivity tester,medical instrument;stabilizing electronic component operating temperature
2.In deep cold circumstances,letting instrument reach safety operating temperature,such as satellite,spacecraft and airplane etc
3.Vacuum heating and baking
4.Car rearview defroster,antenna or radar defrosting heating components and speed regulation resistor
5.Medical treatment and beauty equipment
