DIY Kit Metal Detector DC 3V-5V 60mm Non-contact Sensor Electronic Kits for Security Test

12556
5 9
$2.99 $2.09
Quantity10+50+100+200+300+
Price$1.95$1.89$1.81$1.75$1.65
Contact us for wholesale price
Time Remaining:
- OR - - OR - Add to Wish List

Cheaper Buy Together

$8.93-11%Bundled Price:$7.94
Description:
This is a DIY metal detector kit parts. You need solder it by yourself.

Parameters:
NO. Parameters Value
1 Name Metal detector
2 Operating voltage DC 3-5V
3 Operating current ≤ 40mA
4 Standby current ≤ 5mA
5 Detection depth ≤ 60mm
6 Detection and alarm mode Sound and Light
7 Difficulty of welding machine Easy
8 Circuit board size 86*61mm
9 Packing weight 16g/kit

Component list:

NO. PCB Marker Component Name Parameter QTY
1 R3 RES 470R 1
2 R2 RES 2K 1
3 R1 RES 200K 1
4 VR1 ADJ-RES 100R 1
5 C2.C3 CAP 222P 2
6 C1.C4 CAP 104P 2
7 C5 E-CAP 100UF 1
8 LED1 LED 5mm Red 1
9 Q2.Q3 Triode S9012 2
10 Q1 Triode S9018 1
11 SW1 Power SW 1
12 SP1 Buzzer 9*12 1
13 J1 Power-Socket KF301-2 1
14 —— PCB MDS-60 1
15 Choose Battery box AA1.5V*3 1


Installing Tools:
NOTE! PLEASE PREPARE THE TOOLS TO INSTALL THE KITS.

Electric soldering iron Multimeter Solder wire
Soldering iron holder Diagonal cutting pliers Screwdriver
Tweezers Sharp-nose pliers Solder sucker
Sponge Screwdriver kit


Installation Steps Download:

Diagram:

Finished Product:



#1. Tested by ICStation's Outstanding Partner Workshop MasterOK electronics Repair:

When the Metal is close to DIY Metal Detector , the LED will be on. And it also make some alarm voice.

Learn More Details in the Video:
(The language in the video is Russian)



#2. Tested by ICStation's Outstanding Partner Daniel Heppner:

Learn More Details in the Video:
(The language in the video is English)


#3. Tested by ICStation:

Learn More Details in the Video:



#4. Tested by ICStation's Outstanding Partner MindHand TM:

Learn More Details in the Video:
(The language in the video is Russian)


#5. Tested by ICStation's Outstanding Partner El Taller De TD:

Learn More Details in the Video:
(The language in the video is Spanish)
