1.Introduction:
LED Tower is imitated from Guangzhou Tower. Guangzhou Tower, also known as Guangzhou new TV tower, nickname XiaoManYao. It is the tallest building in Guangzhou, the design of the tower is very characteristic, especially in the night under the lighting decoration, it is beautiful. Now become a landmark in Guangzhou. How can such a beautiful building can not let people heart. We combined with the single-chip micro-chip display technology, we can make the beauty of the Guangzhou Tower. We use STC15F2K60S2 as a control system, the display part is 16*16 dot matrix display, through the production of the Guangzhou Tower, can better enhance the micro-controller on the principle of dot matrix display.
2.Feature:
1>.Bluetooth Audio Controller
2>.Animation Work Mode
3>.Spectrum Work Mode
4>.MP3 Play Mode
5>.Remote Control
6>.Power-off Memory Playback
7>.Built-in 3W Amplifier
8>.Audio Output
9>.TF Card Audio Input
10>.MP3+WAV Lossless Decoding
11>.More than 35 Animation Flashes
12>.More than 8 Spectrum Flashes
13>.Frosted 5mm RGB LED
14>.More than 10-minute Comprehensive Animation Display
15>.Adjustable Animation Flash Speed
16>.Adjustable Spectrum Display Sensitivity
17>.Large Size High Quality Speaker
3.Parameter:
1>.Work Voltage:DC 4.5V~5.5V
2>.Work Current:1300mA
3>.Work Module:Bluetooth and Remote Controller
4>.Work Temperature:-40℃~85℃
5>.Work Humidity:0%~95%RH
6>.Size(Installed):90*90*450mm(Different people installed, the height will be slightly different).
4.Function:
1>. 16*16 led lattice design
2>.A variety of modes can be freely converted:
2.1>.Offline animation mode(More than a dozen)
2.2>.Music spectrum mode(Flash with music)
3>.Plug-in components used to make high success rate
4>.The default code inside the chip, the function is more abundant,So please do not update the code inside arbitrarily!
5.Application:
1>.Training welding skills
2>.Student school
3>.DIY production
4>.Project Design
5>.Electronic competition
6>.Gift giving
7>.Crafts collection
8>.Home decoration
9>.Souvenir collection
10>.Graduation design
11>.Holiday gifts
6.Frequently Asked Questions:
1>. Why some of the LED in the same layer or in the same column can not be bright?
Q:The pin is not soldered firmly or missing.Please check out the soldered pins and fix them again
2>. Why a column or a layer is not bright?
Q:Please refer to the schematic, find the corresponding chip, re-soldering the pin, the chip may be pin soldered or unsoldered.
7.Installation Tips:
1>.User needs to prepare the welding tool at first.
2>.Please be patient until the installation is complete.
3>.The package is DIY kit.It need finish install by user.
4>.The soldering iron can't touch the components for a long time(1.0 second), otherwise it will damage the components.
5>.Pay attention to the positive and negative of the components.
6>.Strictly prohibit short circuit.
7>.This DIY installation is more difficult to be installed, please be patient until the installation is complete!!!
8>.User must install the LED according to the specified rules.Otherwise some LED will not light.
9>.Install complex components preferentially.
10>.Make sure all components are in right direction and right place.
11>.Check that all of the LED can be illuminated。
12>.It is strongly recommended to read the installation manual before starting installation!!!
13>.Please contact us for a complete installation manual!
