Home > Relay Module > Function Relay Module > Trigger Delay Module > AH3-2 Time Relay DC 12V Adjustable Delay Control Timer 8Pin 1s-30s

AH3-2 Time Relay DC 12V Adjustable Delay Control Timer 8Pin 1s-30s

Item ID: GY18963-1

5 9

Price: $10.99

Quantity: - OR - - OR - Add to Wish List

Prev: 6 Channel SPDT Switch Module, DC 24V Relay Module, AC 270V with Isolated Optocoupler DIN Rail Mount High and Low Level Trigger
Next: 5V 1 Channel Relay Module Shield for Arduino ARM PIC AVR DSP SRD

Description:

It is a AH3-2 Time Relay.It mainly adjusts the time through the knob, and the delay accuracy is high. The smaller the time range,the more accurate the adjustment time.

Feature:

1.The shell is made of ABS material,with thick thickness,strong smoothness and fine workmanship.

2.The feet are highly conductive,and each foot has a digital code,which can be inserted into the base correspondingly,which is convenient for installation.

3.It uses a copper core coil,which is safe and stable to use.

4.It has an LED indicator to show the working status.

Parameter:

1.Product Name:AH3-2 Time Relay

2.Product Number:AH3-2

3.Supply Voltage:DC 12V

4.Rated Current:5A

5.Adjustable Delay Range:1s~30s

6.Working Contacts:2 groups of delay contacts

7.Working Mode:Power-on delay

8.Work Temperature:-25℃~85℃

9.Work Humidity:5%~95%RH

10.Size:90*40*50mm

Package:

1pcs AH3-2 Time Relay

1pcs Base
