AC/DC 12V 200ohm Resistor Tester ohmmeter Low Resistance Tester Electrical Instrument LCD Display Impedance Meter

GY16938
5 9
$12.59 $8.81
Contact us for wholesale price
Time Remaining:
- OR - - OR - Add to Wish List



1.Description:
  It is a LCD display resistance tester which can test the resistance of the load.

2.Feature:
  1>.AC and DC dual power supply
  2>.LCD high-definition display
  3>.High precision
  4>.High-quality housing
  5>.Digital dispiay
  6>.Good stability
  7>.Strong anti-interference ability
  8>.Anti-reverse protection

3.Parameter:
  1>.Product Name:Resistance Tester
  2>.Work Voltage:AV/DC 8V~12V
  3>.Work Current:<=15mA
  4>.Measuring Resistance:0ohm~199.9ohm
  5>.Resistance Resolution:0.1ohm
  6>.Work Pressure:80kPa~106kPa
  7>.Work Temperature:-10℃~50℃
  8>.Work Humidity:10%~80%RH
  9>.Size:79.5*43*23mm

4.Note:
  1>.This resistance meter cannot be tested with power on,otherwise it is easy to burn the meter.
  2>.When IN + and IN- are short-circuited,the display shows "000".
  3>.When no signal is input or the range is exceeded, the display shows "1".
  4>.The internal power supply of the resistance meter is connected to the ground of the test terminal, so it is recommended to use two completely isolated temperature power supplies.
  5>.Meter power supply requirements:EI power frequency power supply (silicon steel sheet),Input Voltage 4.5V~5.5V. If using a switching power supply, please use a power supply with a small ripple factor.

5.Package:
  1pcs Resistance Tester
  1pcs XH2.54-4P 10cm wire
